The right layout software depends on project size and on where your team works. Look at HelioScope for commercial rooftop, carport and ground-mount layout. Look at Aurora Solar for remote residential layout, and at RatedPower for utility-scale plants. Look at PVcase or Virto.CAD if your engineers already work in AutoCAD or BricsCAD, which are drawing programs. OpenSolar says its core app is free. SurgePV fits teams that want layout, shading, yield, financial modeling and proposals in one product. It has a published per-user price.
This is a desk comparison of what each vendor publishes, checked October 2026. We have not run side-by-side tests. SurgePV publishes this page and is one of the 10 tools on it.
Criteria used: layout method, project types and size, setbacks and keepouts (areas kept clear of panels), delivery (browser or CAD), published price and trial access.
Laying out roofs? See SurgePV on your next quote
Book a guided demo and bring a real site. We walk through design, yield, finance and the proposal in one platform.
Book a Free DemoChecking cost first? See the SurgePV pricing page.
Best-For Picks by Use Case
- Remote residential layout from imagery: Aurora Solar. Design Mode lists automatic system design, LiDAR-based shade analysis (shade found from laser-scan height data) and AI-assisted 3D modeling. Its Sales Mode page is written around homeowner proposals.
- Commercial rooftop, carport and ground-mount layout with setbacks and keepouts: HelioScope. Its pricing page lists rooftop, carport and ground mount on all projects, and its help center documents setbacks and keepouts.
- Utility-scale plant layout: RatedPower. Its pages describe layout that follows your own setback, road, rotation and slope rules. You can edit the layout by hand. It exports .dwg files (AutoCAD drawing files).
- CAD-based roof and ground engineering: PVcase. Roof Mount and Ground Mount list layout, stringing, cabling, and export of a single-line diagram (a simple drawing of how the system is wired) and a bill of materials (a parts list) on the Professional plan.
- Layout, shading, yield, financial modeling and proposals in one product at a published per-user price: SurgePV. Its product scope lists array layout with these steps. The price is $1,899 per user per year for 1 user. See pricing for 3 and 5 seats. HelioScope Pro and OpenSolar also document several of these steps, so compare them on the table above.
Comparison Table
Listed alphabetically. This is not a ranking; pick by the situation above.
| Tool | Best for | Price (checked October 2026) | Free or paid | Decisive layout fact |
|---|---|---|---|---|
| Arka360 | Residential and commercial design with CRM and permit services | Basic $199 per month (1 user); Premium $358 per month (2 users) (arka360.com) | Paid | “AI-optimized designs within 5 mins” (vendor wording) |
| Aurora Solar | Remote residential layout | Basic $135 per user per month billed annually; Premium $220 per user per month billed annually (aurorasolar.com) | Paid | Automatic system design with pre-strung modules, inverters and BOS components |
| HelioScope | Commercial rooftop, carport, ground mount | Basic $1,620 per license per year; Pro $2,640 per license per year (helioscope.aurorasolar.com) | Paid; 14-day free trial per its help center | Designs up to 1.25 MW (DC) on Basic, 5 MW on Pro, 30 MW on Enterprise |
| OpenSolar | Free core app with layout and proposals | Core app free; API Access and connectors charged from 16 April 2026 (opensolar.com) | Core app free | Auto Design (beta) with automated array placement and a mounting designer |
| PVcase | CAD-based roof and ground engineering | Not published; contact PVcase (pvcase.com) | Paid | Ground Mount “built on AutoCAD”; Roof Mount “3D AutoCAD-based” |
| Pylon | Pay-per-project small installers | Standard $4.00 per project; Pro $10.00 per project (currency not shown) (getpylon.com) | Paid; free credits for five Standard projects | Maximum DC size 30kW on Standard, 99kW+ on Pro |
| RatedPower | Utility-scale PV and hybrid plants | Not published; contact RatedPower (ratedpower.com) | Paid; free product tour | Layout on your setback, road and slope rules; .dwg export and import |
| Scanifly | Drone-verified layout | Not published; book a demo (scanifly.com) | Paid | Remote PrelimDesign and drone-based DroneDesign |
| SurgePV | Layout with shading, finance and proposals | $1,899 per user per year (1 user); see /pricing | Paid; guided demo, no self-serve trial | 3D roof modeling and solar array layout |
| Virto Solar | Concept layout and CAD engineering | Not published; talk to sales (virto.solar) | Paid; free trial on request | Virto.CAD needs AutoCAD or BricsCAD |
Every price above was read on the vendor’s own page in October 2026. Taxes, discounts and plan limits change, so confirm them with the vendor before you buy.
Residential, Commercial or Utility Layout: Which Tools to Check
| Project type | Tools whose pages describe it | What to check |
|---|---|---|
| Residential rooftop | Aurora Solar, OpenSolar, Pylon, Scanifly, Arka360 | Remote imagery quality, proposal output, plan limits |
| Commercial and industrial rooftop | HelioScope, PVcase Roof Mount, Virto.MAX and Virto.CAD, Scanifly, OpenSolar, Arka360, Pylon Pro | Project size limits, setbacks, whether CAD is required |
| Utility-scale ground mount | RatedPower, PVcase Ground Mount, Virto.CAD Enterprise, HelioScope Enterprise | Terrain handling, trackers, CAD round trip |
For trackers, see the solar tracker software list. For racking and structure checks after layout, see the solar structural design list, and for site imagery and mapping, see the solar mapping software list.
Tool Entries
Listed alphabetically. This is not a ranking; pick by the situation above.
Arka360
Arka360 sells design, proposal and lead management software with design and permit services.
Best for: residential and commercial teams that want layout, proposals and a CRM (customer tracking tool) in one product.
Not the right choice if: you need to compare plans before talking to sales. The page’s code also holds other plan tables that are not shown on the page. They include INR (Indian rupee) and further USD figures. Confirm the plan and price that apply to you.
What the vendor documents: the home page lists AI-optimized 3D designs, shading analysis reports and an equipment library. It also lists proposals with financial analysis, built-in CRM tools and on-demand design and permit services. In the US table, Premium adds AI-assisted modeling, battery storage and backup sizing, CAD export and customized proposals.
Price (checked October 2026): Basic is $199 per month and includes 1 user; Premium is $358 per month and includes 2 users; Enterprise is “Talk to Sales”. These are the visible US-dollar plan cards on the pricing page titled “Solar Design Software Pricing USA”. The same page also holds rupee tables, a second rupee set on its /pricing-in page and hidden dollar tables. We do not quote those here. Source: Arka360 pricing.
Limitations: setbacks and keepouts are not stated on the pages we read, and a trial is not stated either.
Vendor link: arka360.com.

Aurora Solar
Aurora Solar sells a solar design and sales platform. HelioScope, listed below, describes itself as an Aurora Inc. company.
Best for: teams that want to lay out a roof remotely and send a proposal from the same product.
Not the right choice if: you want LiDAR-assisted modeling without Premium, because the pricing page lists it on Premium and not on Basic.
What the vendor documents: Design Mode lists remote site assessment, AI-assisted 3D modeling and an in-app CAD engine. It also lists automatic system design. This fills roof surfaces with pre-strung modules, inverters and balance-of-system components (the parts besides panels and inverters). The pricing page lists AI-assisted site models (Aurora AI) and drone mapping on Enterprise. Aurora’s help center has articles titled “How to Design a Ground Mount System” and “How to Design a Reverse Tilt Rack System”.
Price (checked October 2026): Basic is $159 per user per month billed monthly or $135 per user per month billed annually. Premium is $259 per user per month billed monthly or $220 per user per month billed annually. Enterprise is custom. Source: Aurora pricing, North America site.
Limitations: 1 user and 50 projects per month on Basic and Premium. Trial terms are not stated on the pages we read.
Vendor link: aurorasolar.com.

HelioScope
HelioScope is part of Aurora Inc.; its footer reads “an Aurora Inc. Company”.
Best for: commercial rooftop, carport and ground-mount designers who want automatic layout and a keepout-based design in one tool.
Not the right choice if: you need designs above 5 MW (DC), which need Enterprise (up to 30 MW). MW (DC) means megawatts of panel power. You also need Enterprise for single-axis trackers (frames that turn panels to follow the sun).
What the vendor documents: its design page lists a CAD-style interface, automatic layout and shading analysis, with “Intelligent automations in Pro and Enterprise”. The help center documents field segments, keepouts and setbacks. The pricing page lists rooftop, carport, ground mount and battery layout on all projects. On Pro it adds LiDAR-assisted modeling, AI-based obstruction detection and Independent Tilt for fixed-tilt systems (panels at one set angle).
Price (checked October 2026): Basic is $159 per license per month or $1,620 per license per year, each including 1 user and 10 projects per month. Pro is $259 per license per month or $2,640 per license per year. Enterprise is custom per-project pricing. Source: HelioScope pricing.
Limitations: 1 user and 120 projects per year on Basic and Pro. Designs up to 1.25 MW (DC) on Basic and up to 5 MW (DC) on Pro. Standard free trials are 14 days, one per customer (HelioScope help center). HelioScope is delivered in a browser (WebGL), per the help center.
Vendor link: helioscope.aurorasolar.com.

OpenSolar
OpenSolar is a design, sales and project platform that says its core app is free for solar professionals.
Best for: installers who want layout with proposals in a core app the vendor calls free. From 16 April 2026 the vendor charges for API Access (a way for other software to connect) and for connectors.
Not the right choice if: you need a layout feature that is out of beta. The Auto Design page says “Auto Design is in beta and available worldwide”.
What the vendor documents: auto design with automated 3D designs and a bill of materials (a parts list). It lists a mode for setting roof planes and obstructions, with automated solar array placement. It also lists commercial system design, multi-panel systems, and a mounting designer that checks racking (the frames that hold panels) against roof type, slope and panel dimensions. It also lists a single-line diagram generator. Its sales mode page lists use on a tablet or smartphone (iOS or Android) and on PC or Mac.
Price (checked October 2026): the core app is free of charge, per the vendor. The vendor says its partners pay to be on the platform (OpenSolar, Why Free?). From 16 April 2026 the vendor charges for API Access (a per-project fee) and supported connectors (a monthly fee per organization). The per-project API fee is on OpenSolar’s API page. The 16 February 2026 post says accounting connectors are billed as a monthly fee per organization. Enterprise Services are optional and paid: Support US$500 per month, Customize US$1,350 per month, and Enterprise custom. Premium imagery is pay per image, and the app shows the price.
Limitations: the pages we read do not state a project-size or user limit. Imagery, permitting packages and hardware are sold inside the platform.
Vendor link: opensolar.com.

PVcase
PVcase is an end-to-end platform for site selection, PV design and yield, headquartered in Vilnius.
Best for: engineering teams that work in AutoCAD and want automated roof or ground-mount layouts with electrical and bill-of-materials output.
Not the right choice if: you want a browser-only tool, or you need a price before you talk to sales. PVcase says Ground Mount is “built on AutoCAD” and that it does not “offer a complete price list online”.
What the vendor documents: Roof Mount (described on its product page as “3D AutoCAD-based”) lists DWG/DXF conversion (CAD drawing file types) and drone image conversion. It also lists rooftop setbacks, parapets (low walls at roof edges), no-go zones, and layout creation and optimization. Other items are stringing, cabling, single-line diagram export, shading analysis and bill-of-materials export. Ground Mount lists terrain-aware layouts, setbacks, slope and collision analysis, piling analysis, grading, BESS (battery energy storage) and export to PVcase Yield and PVsyst. The page code (structured data) says Ground Mount supports fixed-tilt, east-west and single-axis tracker configurations. A vendor blog post documents Terrain Following Tracker optimization.
Price (checked October 2026): not published. The home page says “We don’t offer a complete price list online because we offer customized packages”, and the pricing pages list a Professional plan with “Talk to sales”. Source: PVcase.
Limitations: the pages we read do not state a trial. The products run on AutoCAD, so check the system requirements in PVcase’s help center.
Vendor link: pvcase.com. For other options, see PVcase alternatives.

Pylon
Pylon is operated by Saru Technologies Pty Ltd, North Strathfield NSW, per its privacy policy.
Best for: small installers who want to pay per project and place panels on aerial imagery.
Not the right choice if: your projects exceed the size limits. The pricing table lists a maximum DC generation size of 30kW on Standard and 99kW+ on Pro. The page lists a project as an address with up to five designs.
What the vendor documents: easy panel placement on aerial imagery. High-resolution imagery is offered in select countries. It also lists unlimited modifications, upload of roof plans and drone imagery, financial projections, and web and PDF proposals. Battery design and commercial-sized projects are listed on Pro. A single-line diagram page is also listed.
Price (checked October 2026): Standard is $4.00 per project and Pro is $10.00 per project; the page shows the dollar sign without a currency code. New users get free credits for five Standard projects. Source: Pylon pricing.
Limitations: its 3D shading simulations page carries a “Coming soon” label. eSignature is listed at 80c per project.
Vendor link: getpylon.com.

RatedPower
RatedPower is now presented as Enverus RatedPower on its own site.
Best for: developers and EPCs laying out utility-scale PV, storage and hybrid plants.
Not the right choice if: you design rooftops. The pages we read describe utility-scale PV, storage and hybrid projects and do not describe rooftop layout. Pricing is not published; contact RatedPower.
What the vendor documents: layout on your own rules for setbacks, roads, structure alignment and rotation. It also uses slope limits and prices cut and fill (earth moving) into CAPEX (the up-front build cost). You can add or remove structures, place string boxes and inverters, and edit connections. It exports the layout as .dwg and imports the edited file. It says the round trip “is not lossless in every case”. Its documents list editable reports, drawings, bills of quantities and single-line diagrams, with a yield model that reconciles with PVsyst.
Price (checked October 2026): not published. The plans page describes plans by use case and lists unlimited projects, users and designs in all plans. It offers a free product tour and a live demo.
Limitations: the pages we read describe utility-scale projects only.
Vendor link: ratedpower.com.

Scanifly
Scanifly sells PV design, field operations and design services.
Best for: teams that want a remote sales layout and a drone-based design that is checked and corrected before install day.
Not the right choice if: you do not fly a drone or want a published price. Scanifly says the drone must have GPS and a high-resolution camera, and pricing is not published on the pages we read.
What the vendor documents: PV Design lists two tools. PrelimDesign uses satellite or Nearmap imagery with LiDAR-enabled shading, for residential, commercial and ground mount. DroneDesign makes a 3D model from drone data, “accurate to within 1-3 inches of hand measurements”, in the vendor’s words. Pro Design lists customized roof layouts, fire setbacks, module type and orientation, and shading analysis. It also lists export to CAD or to racking partners. Scanifly also offers design services.
Price (checked October 2026): not published. The site directs you to Book a Demo.
Limitations: the 1-3 inch figure is the vendor’s statement and we have not checked it.
Vendor link: scanifly.com.

SurgePV
SurgePV is our product. We publish this list and sell this software.
Best for: installers and EPC teams (companies that design and build solar projects) that want 3D roof modeling and array layout in the same web application as shading, yield, financial modeling and proposals.
Not the right choice if:
- you need a self-serve trial. SurgePV offers a guided demo and does not advertise one.
- you need terrain modeling or utility-scale plant layout. SurgePV’s published scope lists roof modeling and array layout, and RatedPower and PVcase Ground Mount document ground-mount layout.
- you work in CAD and want layouts inside AutoCAD. PVcase and Virto.CAD document that.
- you want free software. OpenSolar says its core app is free (API Access and connectors are charged from 16 April 2026).
- you need approval from a lender, authority or engineer. SurgePV outputs support design and documentation but do not replace that approval.
- you need a full CRM, or a monitoring or ERP (business management software) product. SurgePV’s published product scope does not list a CRM. It is not a monitoring or ERP product.
What the vendor documents: the product scope lists 3D roof modeling, solar array layout and shading analysis. It also lists energy-yield modeling and financial modeling. Other items are electrical workflow support, bill-of-materials output and proposal generation. See SurgePV solar design software and SurgePV for residential solar.
Price (checked October 2026): $1,899 per user per year for one user, $1,499 per user per year for 3 seats, and $1,299 per user per year for 5 seats. The pricing page lists unlimited projects, shadow analysis, generation and financial analysis, and proposal generation under “Everything included”. Access starts with a guided demo.
Limitations: results depend on the source data, assumptions and equipment models you use. Pricing, product access and contract terms are confirmed in a written quote.
Vendor link: SurgePV solar design software.

See SurgePV layout on a roof you are quoting
Book a guided demo and bring a roof with obstructions.
Book a Free DemoNo commitment required · 20 minutes · Live project walkthrough
Virto Solar
Virto Solar sells Virto.MAX (concept design), Virto.CAD (CAD plugin) and Virto.CORE (for mounting manufacturers).
Best for: commercial and industrial (C&I) teams that want a concept layout product and a CAD engineering product from one vendor.
Not the right choice if: you do not have AutoCAD or BricsCAD, because Virto.CAD’s FAQ says “you need either AutoCAD or BricsCAD”. Pricing is not published; both plans pages say “Talk to sales”.
What the vendor documents: Virto.MAX Lite is “Best suited for c&I PV Design”. It has 3D modeling and automated layout, financial analysis and battery sizing. Mega covers designs bigger than 1MW. Virto.CAD lists automated module layout and shadow analysis. It also lists automated string plans and obstacle setbacks. Professional is for roof projects. Advanced is for ground-mounted, floating, carport and rooftop projects. Enterprise is for utility ground mount. Virto.MAX is offered in five languages (EN, NL, FR, DE, ES).
Price (checked October 2026): not published. A free trial can be requested through sales. Source: Virto.MAX pricing page.
Limitations: the Virto.MAX pricing pages do not state how it is delivered; its product page mentions “browser-based access to interactive project designs”.
Vendor link: virto.solar.

How to Choose Solar Layout Software
Match the tool to your project mix, then test the shortlist on your hardest recent roof or site. Auto-layout and imagery quality vary by roof, so check each tool against a site survey or photos before a design goes to a customer. See also our solar panel layout design guide and the comparison of east-west and south-facing layouts.
How We Ordered These Tools
The tools are listed alphabetically, and the table records what each vendor documents, not what we saw in use. “Not stated” means the pages we read did not say; the feature may still exist.
| Tool | Layout method | Project types and size | Setbacks and keepouts | Delivery | Price published |
|---|---|---|---|---|---|
| Arka360 | AI-optimized designs | Residential and commercial | Not stated | Not stated | USD per month (US plan cards) |
| Aurora Solar | Automatic system design | Not stated on the Design Mode page | Not stated | Not stated | USD per user per month |
| HelioScope | Automatic layout, more automation on Pro | Rooftop, carport, ground mount; up to 30 MW (Enterprise) | Setbacks and keepouts | Browser (WebGL, per help center) | USD per license |
| OpenSolar | Auto Design (beta), automated array placement | Commercial design documented | Obstruction setting mode | Tablet, smartphone, PC or Mac (sales mode page) | Core app free, per vendor |
| PVcase | Automated layouts | C&I rooftop; utility-scale ground mount | Setbacks, parapets, no-go zones | AutoCAD | Not published |
| Pylon | Panel placement on imagery | Up to 30kW (Standard), 99kW+ (Pro) | Not stated | Web application | USD per project (currency not shown) |
| RatedPower | Layout on your rules, editable | Utility-scale PV, storage, hybrid | Setbacks, roads, slope limits | Not stated | Not published |
| Scanifly | AI layout or design services | Residential, commercial, ground mount | Fire setbacks | Not stated | Not published |
| SurgePV | Solar array layout | Roof modeling and array layout (scope) | Not stated | Web application | USD per user per year |
| Virto Solar | Automated layout | C&I; carport, rooftop, floating, ground mount | Obstacle setbacks (CAD) | Virto.CAD: AutoCAD or BricsCAD; Virto.MAX: browser access to designs (product page) | Not published |
Layout method. It matters because the method decides how much manual drawing is left. We did not time any layout.
Project types and size. It matters because size caps and project types rule tools out early. We did not test large or irregular sites.
Setbacks and keepouts. It matters because fire and building setbacks decide how many modules fit. We did not check any tool against a local code.
Delivery. It matters because a CAD plugin needs a CAD license and a browser tool does not. We did not test performance or offline use.
Price published. It matters because a published number lets you plan a budget. We left out add-ons, taxes and volume discounts, and we did not negotiate quotes.
SurgePV sits in the alphabetical list like the other nine. It is the best-for pick only where layout in the same web application as shading, yield, financial modeling and proposals is the deciding factor. For commercial layout with documented setbacks and keepouts, HelioScope is the better documented fit. For utility-scale plants, RatedPower and PVcase are.
Related lists
For related comparisons, see best solar design software, best ground-mount design software, best roof modeling software and best shading analysis software.
Sources and Dates
Vendor pages were read in October 2026. Arka360 (Arka360 pricing, arka360.com). Aurora Solar (Design Mode, Aurora pricing, aurorasolar.com). HelioScope (design page, help center, HelioScope pricing, help center, help center, helioscope.aurorasolar.com). OpenSolar (Auto Design page, mounting designer, sales mode page, OpenSolar, Why Free?, OpenSolar’s API page, 16 February 2026 post, Enterprise Services, opensolar.com). PVcase (Roof Mount, product page, Ground Mount, vendor blog post, PVcase). Pylon (privacy policy, single-line diagram, Pylon pricing, getpylon.com). RatedPower (plans page, ratedpower.com). Scanifly (PV Design, scanifly.com). Virto Solar (Virto.MAX pricing page, product page, virto.solar). Other sources: virto.solar. SurgePV pricing is on the SurgePV pricing page.
Frequently Asked Questions
What is solar layout software?
Solar layout software places solar modules (panels) on a roof or site. It lays out the array within the setbacks (required gaps from roof edges), obstructions and equipment limits you set. Most tools also string the array (wire panels into chains) and estimate production. Some export to CAD (computer-aided design, drawing software). Some produce electrical drawings. What each tool adds beyond placement differs, so check the comparison table.
What is the best free solar layout software?
OpenSolar says its core app is free of charge for solar professionals. The vendor charges for API Access (a way for other software to connect) and supported connectors from 16 April 2026. OpenSolar documents auto design and a mounting designer. Pylon gives new users free credits for five Standard projects, and Virto.MAX offers a free trial on request. HelioScope’s help center says standard free trials are 14 days, limited to one trial per customer.
How much does solar layout software cost?
Published prices use different units. Aurora lists $135 or $220 per user per month billed annually. HelioScope lists $1,620 or $2,640 per license per year. Pylon lists $4.00 or $10.00 per project. Arka360 lists $199 or $358 per month. SurgePV lists $1,899 per user per year for one user. OpenSolar says its core app is free, but the vendor charges for API Access and supported connectors from 16 April 2026. PVcase, RatedPower, Scanifly and Virto do not publish a price on the pages we read.
Which solar layout software handles ground-mount and utility-scale projects?
RatedPower describes layout for utility-scale (very large) PV, storage and hybrid plants, with editable setbacks, roads and slope limits. PVcase Ground Mount is built on AutoCAD for utility-scale layouts that follow the terrain. Virto.CAD lists utility ground mount on its Enterprise plan. HelioScope lists designs up to 30 MW (DC) and single-axis trackers (frames that turn panels to follow the sun) on Enterprise.
How do PVcase and Virto.CAD differ?
Both work inside CAD, which is drawing software for engineers. PVcase says Ground Mount is built on AutoCAD and describes Roof Mount as 3D AutoCAD-based. Virto.CAD requires either AutoCAD or BricsCAD. PVcase sells separate Prospect, Ground Mount, Roof Mount and Yield products. Virto splits its range into MAX, CAD and CORE. Neither publishes a price on the pages we read.
Do I need LiDAR or drone data for an accurate solar layout?
It depends on the roof and the trees around it. LiDAR uses laser scans to measure height. Aurora lists LiDAR-assisted modeling on Premium, and HelioScope lists it on Pro. Scanifly uses drone-based data for its DroneDesign product. Whatever the tool, compare the model against a site survey or photos before the design is sold.
