Reconcile the layout and single-line diagram against one accepted project configuration, not against appearance or matching timestamps. Compare governed quantities, exact equipment, grouping relationships, connection basis, and revision purpose. Record matches, qualified mappings, conflicts, and unknowns; route technical decisions to the responsible reviewer and release only the supported package for its named use. Matching drawings are not proof of electrical compliance.
A layout and a single-line diagram describe different views of the same solar project. The layout records physical placement; the SLD represents electrical relationships at its intended level of detail. They do not need to look alike, but their governed project facts must be reconcilable.
This guide gives installers and EPCs a baseline comparison method. It is not a string design, equipment compatibility assessment, conductor or protection calculation, code interpretation, installation instruction, or professional approval. The responsible qualified reviewers and applicable authorities determine those matters.
Start With the Configuration, Not the Filenames
Identify the project, building or phase, selected option, current accepted equipment basis, layout revision, SLD revision, and intended release. A single address may contain multiple configurations. A later timestamp may still contain older data.
Record the source for each governed fact and name the owner of the comparison. Use the accepted project record to resolve conflicts rather than choosing whichever drawing looks newer. An unapproved equipment substitution should not become the basis merely because it appears in an export.
Section 6.4 of the 2018 NREL PV and storage O&M guide discusses document versions, change history, contacts, and retained equipment and as-built records. Those lifecycle practices support continuity; they do not establish technical correctness or release authority.
Compare Shared Facts and Explain Different Representations
Not every layout detail appears on an SLD, and not every electrical detail appears on a roof drawing. A qualified mapping can explain a legitimate difference. Absence of a visible label does not by itself prove either a conflict or no impact.
| Comparison | Evidence to use | Question for the responsible reviewer |
|---|---|---|
| Project and option identity | Configuration record and release manifest | Do these artifacts describe the same selected option and phase? |
| Module quantity and identity | Accepted layout and exact equipment records | Are quantities and product references reconciled at the intended detail? |
| Array and electrical grouping | Current design record and mapping | Does physical grouping correspond to the electrical configuration or have an explained relationship? |
| Inverter and other equipment | Accepted selections and equipment schedule | Does the SLD represent the current equipment and relationships? |
| Storage and connection basis | Current scope and qualified technical records | Is the depicted topology current for the selected configuration? |
| Routes or modeled assumptions | Governing design and technical basis | Does a physical change affect a source used by the electrical output? |
| Release purpose | Package manifest and review dispositions | Are both artifacts suitable for the same named use? |
Sandia’s PVPMC mismatch guidance explains that series-connected devices share current and parallel-connected devices share voltage. This modeling context shows why grouping is a material relationship, not merely a drafting label. It supplies no project stringing instruction or equipment approval.
Matching module count is one check, not a certificate of agreement. Equipment identity, arrangement, relationship, and source revision can still differ. Conversely, a layout annotation may change without requiring a new electrical representation; the responsible reviewer should record that disposition.
Use Explicit Comparison States
| State | Meaning | Next action |
|---|---|---|
| Match | The field agrees with the accepted source | Continue with other checks |
| Mapped | Different representations describe a qualified common basis | Retain the mapping and reviewer |
| Not displayed | One artifact intentionally omits the visible detail | Check the underlying dependency before concluding no impact |
| Conflict | Artifacts assert incompatible current facts | Restrict the affected release and resolve through evidence and authority |
| Unknown | Evidence is insufficient to judge the relationship | Assign an owner, required review, and affected-use restriction |
| Qualified | A responsible decision accepts a bounded difference for a named use | Retain its limits and successor condition |
| Superseded | A prior artifact is historical | Keep it out of active release locations while retaining history |
These are an editorial control framework, not a substitute for the organization’s technical or statutory approval process. A blank field should not be interpreted as a favorable disposition.
Keep Automation Within Its Demonstrated Scope
PVsyst’s SLD documentation describes diagram updates from particular system dialogs and notes that changing components can affect grouping. It also states limitations on the diagram’s supported configurations and included components. This is a vendor-specific example: an automatically updated view still has a defined scope and needs interpretation.
In the actual tool, confirm which inputs drive which output, what is excluded, and whether an exported file changes with the underlying model. A refreshed live view does not prove that an older issued PDF has been superseded. Do not assume native synchronization or approval from a shared software interface.
Reconcile Downstream Artifacts Without Duplicating the Technical Design
After the comparison, inspect the equipment list, BOM, customer scope, relevant submission package, and crew handoff pack where they consume the same configuration. Record a correction, supported non-impact decision, or bounded qualification for each affected item.
The purpose is to carry the reviewed basis forward, not to re-create electrical calculations in a project-management spreadsheet. Route compatibility, protection, interconnection, structural, safety, or other qualified questions to their responsible process.
When a layout revision initiates the review, use the detailed layout-change-to-SLD impact record. That guide owns the event sequence and copy-ready revision fields; this page is the baseline comparison of the two current views.
Release the Named Package With Its Limits
The release record should identify included versions, purpose, responsible dispositions, outstanding conditions, affected-use restrictions, and recipients. A preliminary concept should not silently become a procurement or construction instruction.
Confirm distribution of the current package where required. Receipt is not evidence of electrical approval or correct execution. Preserve prior revisions and the reason for change, and reopen the affected review when new information alters the accepted basis.
Use field-change communication when site evidence conflicts with the issued record. Applicable safety or project directions may require a wider stop than the named documentation task; this guide does not define safe work boundaries.
Evaluate a Layout-to-SLD Comparison
Bring an accepted configuration and its two outputs to a SurgePV demo. Ask which fields drive the demonstrated workflow, how revisions are identified, and what remains for qualified review.
Book a DemoExplore Solar DesigningFrequently Asked Questions
What is the first layout-to-SLD check?
Confirm that both artifacts belong to the same accepted project configuration, option, and intended release. Then compare governed facts against their sources rather than filenames or timestamps.
Does matching module count prove that the drawings agree?
No. Equipment identity, grouping relationships, connection basis, revisions, and release purpose can still differ. Record the relevant comparisons and qualified mappings.
Does every difference require redrawing the SLD?
No. Some differences reflect intentionally different detail or a change with no electrical effect. The responsible reviewer determines the impact and records the evidence, disposition, and any restriction.
Can generated documents prove electrical compliance?
No. Shared data or generated drawings do not replace applicable technical calculations, equipment instructions, qualified review, safety processes, or authority decisions.
