Lead Acid Battery Solar Storage Design: AGM & DoD

Lead acid battery solar storage design: size flooded, AGM and tubular banks with DoD, autonomy and temperature corrections, plus a worked example.

Keyur Rakholiya

Written by

Keyur Rakholiya

CEO & Co-Founder · SurgePV

Rainer Neumann

Edited by

Rainer Neumann

Editorial contributor · SurgePV

Published ·Updated

Answer

Lead acid battery solar storage design sizes a deep-cycle bank from daily load, days of autonomy, depth of discharge, temperature correction and design margin. Trojan's sizing guideline multiplies daily amp-hours by the temperature, autonomy and margin factors, then divides by depth of discharge. In the worked example, a 1.96 kWh daily load needs about 18 kWh of nominal battery energy.

Last updated: November 2026

Lead-acid is the oldest rechargeable battery chemistry, and it is easy to size wrong. A lead-acid bank that looks large on paper can deliver far less than its rating in cold weather, wear out early from deep daily cycling, or become a safety risk if it is installed without ventilation.

This guide covers lead acid battery solar storage design for solar installers, EPCs and technically minded homeowners who need to size a bank from first principles. It relies on Trojan Battery’s published user guide, white paper and sizing guideline, the IRENA and World Health Organization health-care electrification guide, and a published cost model from Heaven Green Energy, the author’s company. SurgePV publishes this post and sells solar design software. If you are comparing chemistries, the author’s related guide on lithium vs lead-acid total cost explains when each chemistry wins over a 10-year horizon.

When Does Lead-Acid Still Make Sense in 2026?

Lead-acid still makes sense when upfront cost, occasional use or harsh conditions matter more than lifetime cost. Lithium iron phosphate (LFP) has taken over most daily-cycling residential and commercial storage, so lead-acid now has a narrower role.

Lead-acid wins on sticker price. In its 2026 Indian price table, Heaven Green Energy lists tubular lead-acid at ₹15,000 to ₹18,000 per nominal kWh against ₹35,000 to ₹45,000 per kWh for LFP. The same table lists usable depth of discharge at 50 percent for lead-acid and 80 to 100 percent for LFP, which narrows the price gap once you pay per usable kWh. Those are Indian retail prices from one installer, so treat them as an example, not a global benchmark.

Lead-acid also has practical advantages. Trojan’s user guide gives a recommended operating range of minus 20 to 45 degrees Celsius for its flooded Solar Premium line and minus 20 to 50 degrees Celsius for its AGM line. Lead-acid has an established recycling route, and a simple charge controller can run a bank without a lithium-style battery management system.

The three best fits for lead-acid are:

  • Seasonal off-grid cabins that cycle only a limited number of times per year.
  • Budget backup systems where the owner accepts earlier replacement.
  • Telecom, irrigation and rural DC loads with proven maintenance routines.

For daily-cycling homes and businesses, the lower lifetime cost usually belongs to LFP. The exception is a market where lithium import duties, currency risk or after-sales support make lead-acid the safer operational choice.

Which Lead-Acid Chemistry Suits Solar?

Only deep-cycle batteries suit solar. Starter batteries are built for short bursts of high current and fail quickly in deep-cycle service. Solar storage needs batteries designed to discharge slowly over many hours and recharge the next day.

Trojan’s white paper on selecting lead-acid technology compares the three main types, and the table below summarizes it.

Flooded Lead-Acid

Flooded, or wet-cell, batteries have liquid sulfuric acid electrolyte over the plates. Per Trojan’s white paper they are generally the least expensive lead-acid type, rate best for deep-cycle capability and have the highest energy density. They release hydrogen and oxygen during charging, must be vented and kept upright, and need water replaced periodically.

Absorbed Glass Mat

AGM batteries hold the electrolyte in a glass fiber mat. They are sealed, can be mounted on their sides and have much lower ventilation needs. Trojan’s white paper rates AGM best at low temperatures and best for high discharge currents. AGM batteries must not be severely overcharged, and the charger must have an AGM setting.

Gel

Gel batteries immobilize the electrolyte with a thickening agent. Trojan’s white paper says they have a higher initial cost than AGM, do not suit high-power applications, and generally outlast an AGM in deep-cycle use unless the AGM is designed for deep cycling. They also need a charger with a gel setting and temperature compensation.

Tubular Flooded

Tubular batteries use tube-shaped positive plates and are common in India, where Heaven Green Energy’s cost model lists 1,200 to 1,500 cycles at 50 percent depth of discharge for tubular lead-acid. Cycle life varies widely by model, so use the datasheet for the exact battery you plan to specify.

Factor Flooded AGM Gel
Sealing Vented, releases H2 and O2 when charging Low to no gassing unless overcharged Low to no gassing unless overcharged
Maintenance Periodic water replacement Maintenance-free Maintenance-free
Mounting Upright only Upright or on its side Upright or on its side
Deep-cycle capability Best Better Better
Low-temperature performance Good Best Fair
Self-discharge Up to 15% per month 1 to 3% per month 1 to 3% per month
Round-trip efficiency 70 to 80% 80 to 90% 80 to 90%
Relative cost Lowest Middle Highest

Source: Trojan Battery white paper, “Selecting the Proper Lead-Acid Technology”, published on trojanbattery.com. The right choice depends on duty cycle, climate, maintenance capacity and budget. Most mistakes start with putting the wrong chemistry in the wrong application.

Key Takeaway

Flooded batteries are the cheapest and best at deep cycling, but they only work where someone will water them and the room is ventilated. Choose AGM when you cannot guarantee maintenance.

What Five Parameters Determine Lead-Acid Bank Life?

Five parameters interact in a lead-acid bank: depth of discharge, cycle life, days of autonomy, temperature and round-trip efficiency. Ignore any one of them and the bank will underperform.

1. Depth of Discharge

Depth of discharge (DoD) is the percentage of a battery’s rated capacity removed in one cycle. A joint IRENA and World Health Organization guide recommends 50 percent DoD for lead-acid batteries, so they are not discharged by more than half their capacity, according to the IRENA and WHO Energizing Health Care report (2023). A 200 Ah battery at 50 percent DoD delivers 100 Ah of usable capacity.

Trojan’s sizing worksheet allows a DoD factor from 0.2 to 0.8. It lists 0.5 as typical and 0.2 as recommended, and suggests shallow daily cycling with occasional deeper discharge, up to 80 percent, on cloudy days. For more detail, see the depth of discharge guide.

2. Cycle Life

Cycle life is the number of charge-discharge cycles a battery delivers before capacity falls below its end-of-life threshold. It depends heavily on DoD, temperature and charging, so read the cycle-life curve in the datasheet for your exact model. Trojan also notes that life is difficult to predict and varies with application, frequency of use and maintenance. Cycling deeper every day means replacing the bank sooner.

3. Days of Autonomy

Autonomy is the number of days the battery must supply the load with no solar input. Trojan’s sizing guidelines give a range of 2 to 10 days. They recommend 5 days for stand-alone solar and a minimum of 2 days for hybrid systems. More autonomy means a larger and more expensive bank, but it also reduces average DoD.

4. Temperature

Lead-acid capacity falls as temperature falls. Trojan’s sizing guidelines publish correction factors by chemistry, shown below. A flooded battery at 0 degrees Celsius needs 1.39 times the nominal capacity of one at 25 degrees Celsius. Trojan’s user guide also notes that battery life diminishes as temperature rises. For stand-alone power system design in Australia and New Zealand, see AS/NZS 4509.2 and check the standard for its temperature and array-sizing requirements.

Battery temperature Flooded AGM Gel
25 °C (77 °F) 1.00 1.00 1.00
10 °C (50 °F) 1.19 1.08 1.11
0 °C (32 °F) 1.39 1.20 1.25
-10 °C (14 °F) 1.70 1.35 1.42
Trojan temperature correction factor for flooded lead-acid batteries (multiplier on required capacity)
  • 25 °C1x
  • 10 °C1.19x
  • 0 °C1.39x
  • -10 °C1.7x

Source: Trojan Battery Sizing Guidelines (TRJN0168), temperature correction table, checked November 2026.

5. Round-Trip Efficiency

Round-trip efficiency is the share of energy put into the bank that comes back out. Trojan’s white paper gives 70 to 80 percent for flooded batteries and 80 to 90 percent for VRLA types (AGM and gel). Heaven Green Energy’s model lists 80 to 85 percent for tubular lead-acid and 95 to 98 percent for LFP. Either way, the lead-acid system needs more solar generation to deliver the same load. For more detail, see the round-trip efficiency guide.

How Do You Size a Lead-Acid Battery Bank Step by Step?

Size the bank in five steps: audit the load, choose autonomy, apply depth of discharge, apply corrections, then convert to amp-hours. The structure follows Trojan’s published sizing form, in which required amp-hours equal daily amp-hours times the temperature factor, days of autonomy and design margin, divided by depth of discharge.

Step 1: Audit the Daily Load

List every load, its wattage and its daily run time. Multiply watts by hours to get watt-hours per day. Include inverter losses. Trojan’s worksheet uses the average inverter efficiency over the day, and 0.80 if it is not known.

For a small off-grid cabin the load table might look like this:

Load Watts Hours/day Wh/day
LED lights 30 5 150
Fridge 100 8 800
Fan 50 6 300
Phone/laptop charging 50 4 200
Water pump 300 0.5 150
Inverter standby 15 24 360
Total 1,960

The daily load is 1.96 kWh. Trojan’s worksheet gives a design margin of 1 to 1.25 and recommends 1.10. Applying 1.10 gives 2.16 kWh per day. This is an illustrative worked example, not a measured project.

Step 2: Choose Days of Autonomy

For an off-grid cabin with occasional cloudy stretches, this example uses 3 days of autonomy, which is below Trojan’s 5-day recommendation for stand-alone solar and accepts more outage risk to hold cost down. The energy the bank must store is 2.16 kWh times 3, or 6.48 kWh of usable energy.

Step 3: Apply Depth of Discharge

Use the typical DoD of 0.5. Divide usable energy by DoD to get nominal energy: 6.48 kWh divided by 0.50 equals 12.96 kWh. A more aggressive 60 percent DoD would drop that to 10.8 kWh but shorten battery life.

Step 4: Apply Temperature and Efficiency Corrections

If the flooded batteries operate at 10 degrees Celsius in winter, Trojan’s correction factor is 1.19, so 12.96 kWh becomes 15.42 kWh. This example then divides by an 85 percent round-trip efficiency, an assumption of this guide that Trojan’s worksheet handles through inverter efficiency in the load table. The result is 15.42 divided by 0.85, or about 18.1 kWh of corrected nominal energy.

Step 5: Convert to Amp-Hours at System Voltage

For a 24-volt system, 18.1 kWh divided by 24 volts equals about 756 Ah. Round up to a standard battery size. A practical bank might use eight 6-volt 390 Ah batteries, four in series per string and two strings in parallel, giving 780 Ah at 24 volts.

Ah required = (Daily load kWh × Margin × Autonomy days × Temp factor) / (System voltage × DoD × Efficiency)

Trojan’s Battery Sizing Guidelines (document TRJN0168, 2010) set out the same adjustment factors. The document recommends a maximum of 6 parallel strings for better charge balance. The efficiency term in the formula above is this guide’s addition.

Pro Tip

Run the sizing twice, once with the winter battery temperature and once with the summer one. If the winter result is far larger, either insulate the battery enclosure or accept a larger bank. Do not size for the summer number.

Pairing a battery bank with a solar array?

Model array layout, shading and energy yield for the PV side of an off-grid or hybrid project before you fix the battery size.

Book a Demo

Checking cost first? See the SurgePV pricing page

How Should You Charge and Manage a Lead-Acid Bank?

A correctly sized lead-acid bank still fails early if it is charged wrong. The settings below come from Trojan’s Battery User’s Guide and apply to Trojan products at 25 degrees Celsius. Other makers publish different values, so always use the datasheet for your battery.

Setting Flooded (Solar Premium, Signature) AGM
Maximum bulk charge current 13% of C20 (10 to 13% recommended) 20% of C20
Absorption voltage 2.45 V per cell (14.7 V on 12 V) 2.40 V per cell (14.4 V on 12 V)
Float voltage 2.25 V per cell (13.5 V on 12 V) 2.25 V per cell (13.5 V on 12 V)
Equalization voltage 2.70 V per cell (16.2 V on 12 V) Never equalize
Temperature compensation minus 5 mV per cell per °C minus 5 mV per cell per °C

Bulk, Absorption and Finish

Trojan recommends a three-phase profile for flooded batteries. In bulk, constant current of 10 to 13 percent of C20 is applied until the voltage reaches the absorption voltage. In absorption, voltage is held constant while current falls. In the finish phase, 1 to 3 percent of C20 is applied until the battery is full. For a 400 Ah bank, bulk current is 40 to 52 amps. AGM batteries use a two-phase profile with 20 percent of C20 for bulk.

Float

Float voltage keeps an idle battery topped up. Trojan advises avoiding continuous float on flooded batteries that are charged more than once a week, and on VRLA batteries charged more than once a month.

Equalization

Equalization is a controlled overcharge of fully charged flooded batteries. It reduces stratification and sulfation. Trojan recommends equalizing for 2 to 4 hours about every 30 days, or when specific gravity is below 1.235 after charging, or when the range between cells is more than 0.030 points. Deep-cycle AGM and gel batteries should never be equalized.

Temperature Compensation

All charging voltages need temperature compensation. Trojan gives a coefficient of minus 5 millivolts per cell for each degree Celsius above 25. On a 12-volt battery with 6 cells that is 0.03 volts per degree, so a battery at 35 degrees Celsius needs 0.3 volts less than at 25. Trojan says compensation is desirable for all batteries and should always be used with AGM and gel.

What Do Installation, Ventilation and Safety Require?

Lead-acid banks are heavy, release gas and contain corrosive acid. Follow the battery manufacturer’s installation guide and local electrical code, and use the points below as a starting checklist.

  • Ventilation. Trojan’s user guide says to charge batteries only in well-ventilated areas. A lead-acid safety data sheet from Trojan warns that hydrogen is highly flammable and can accumulate where ventilation is poor. AGM and gel release much less gas than flooded batteries, but still need airflow for temperature control.
  • Spill response. Trojan’s checklist says to neutralize small spills with baking soda and water, and never to leave a spill unattended. Check local code for containment requirements.
  • Cables and fusing. Trojan says to use short cables of appropriate size to minimize voltage drop and to check connections for proper torque. Fuse each string as your design and local code require, with DC-rated protection.
  • Spacing. Trojan specifies a minimum of 12.7 mm (0.5 inch) between batteries for airflow. Keep the room cool, because battery life diminishes as temperature rises.
  • Protective equipment. Trojan lists protective clothing, gloves and safety goggles, insulated tools, and no smoking or sparks near batteries.

What Does Lead-Acid Cost Against Lithium Over 10 Years?

The upfront price gap between lead-acid and lithium is real, but lead-acid banks may need replacement more often, lose more energy as heat and carry maintenance costs. How much that matters depends on cycling frequency and local prices.

Heaven Green Energy’s published 8-variable total-cost model is one worked comparison. For a 5 kWh usable residential system at 2026 Indian retail prices, it gives roughly ₹4,29,000 over 10 years for tubular lead-acid against ₹1,90,000 for LFP, according to the Heaven Green Energy lithium vs lead-acid guide. The model assumes one full cycle a day, a 10-year horizon, a lead-acid replacement at year 5 and a 7 percent opportunity cost on capital. Heaven Green Energy is the author’s company, so read the figures as one installer’s model.

10-year total cost of a 5 kWh usable residential battery (installer model, India) (rupees, lakh)
  • LFP (lithium iron phosphate)₹1.9 lakh
  • Tubular lead-acid₹4.29 lakh

Source: Heaven Green Energy lithium vs lead-acid guide (author's company; 2026 Indian retail prices, one-cycle-per-day assumption), checked November 2026.

The lead-acid case improves when the bank cycles only occasionally, sits in a ventilated space already, or faces a hard budget cap. For daily cycling, the same model finds LFP the lower-cost choice.

What Are the Most Common Lead-Acid Design Mistakes?

Most lead-acid failures trace back to a short list of avoidable errors.

  • Using starter batteries. Starter batteries are not built for deep cycling. Specify deep-cycle batteries.
  • Sizing for nameplate capacity. A 200 Ah battery at 50 percent DoD gives 100 Ah of usable energy. Size for usable capacity.
  • Forgetting temperature derating. Apply the lowest expected battery temperature to the capacity calculation.
  • Installing flooded banks without ventilation. Hydrogen can accumulate in poorly ventilated rooms. Keep flooded banks out of sealed cabinets.
  • Setting charge voltages wrong. Use the maker’s settings with temperature compensation. This is critical for AGM and gel, which cannot be topped up with water, and Trojan warns that water should never be added to AGM or gel batteries.
  • Mixing old and new batteries. Replace a failed string as a set, so a new battery is not overcharged next to worn ones.
  • Chronic undercharging. Batteries left partly charged lose capacity to sulfation. Make sure the array can fully recharge the bank, even in winter.

Which Tools Help With Lead-Acid Sizing?

Manual sizing teaches the physics, but design software reduces errors and speeds up iteration. Look for a tool that lets you change load, autonomy, DoD and temperature and see the effect on bank size.

For a first pass, the battery storage design software guide reviews platforms that model solar-plus-storage projects. For off-grid projects, see the off-grid solar system sizing calculator guide. For backup-only systems, the backup power solar battery design guide covers load prioritization and outage duration.

See how storage fits into a solar design workflow

Walk through SurgePV’s storage design page and a live project to check what is available for your battery sizing needs.

Book a Demo

Want the numbers first? Read the SurgePV pricing page

Frequently Asked Questions

What is lead acid battery solar storage design?

Lead acid battery solar storage design is the process of sizing, selecting and configuring a deep-cycle lead-acid bank for a photovoltaic system. It balances daily energy use, backup duration, depth of discharge, temperature, charging profile and safety so the bank delivers reliable power over its expected life.

How do you size a lead-acid battery bank for solar?

Start with the daily load in amp-hours, multiply by temperature, days-of-autonomy and design-margin factors, then divide by depth of discharge. That is the form Trojan uses in its Battery Sizing Guidelines. Convert the result to battery strings using the battery rating and system voltage.

What depth of discharge should you use for lead-acid solar batteries?

Plan around 50 percent depth of discharge for lead-acid solar batteries. The IRENA and WHO guide recommends 50 percent, and Trojan’s sizing worksheet gives 0.5 as the typical value with 0.2 recommended for shallow daily cycling. Deeper discharge shortens battery life.

Are flooded or AGM batteries better for solar storage?

Flooded batteries suit sites where someone can water them and the room is ventilated, while AGM suits sites that cannot be maintained. Per Trojan’s white paper, flooded batteries are generally the cheapest and need periodic watering. AGM batteries are sealed and maintenance-free but must be charged with an AGM setting.

What charging voltage should a lead-acid solar bank use?

Use the battery maker’s published settings, because they differ by product line. Trojan lists 2.45 volts per cell for absorption and 2.25 for float on its Solar Premium flooded line, which is 14.7 and 13.5 volts on a 12-volt battery. Apply temperature compensation of minus 5 millivolts per cell per degree Celsius above 25.

How does temperature affect lead-acid battery sizing?

Cold weather reduces usable capacity, so the bank must be larger. Trojan’s sizing guideline applies a correction factor of 1.19 for flooded batteries at 10 degrees Celsius and 1.39 at 0 degrees Celsius. Size for the lowest battery temperature you expect.

Is lead-acid still worth using for solar storage in 2026?

Lead-acid still makes sense for tight budgets, occasional use and sites with a ventilated battery room. For daily cycling, one Indian cost model from Heaven Green Energy finds lithium iron phosphate cheaper over 10 years. Compare both chemistries with your own cycling pattern and local prices.

To see what SurgePV publishes for battery sizing, read the solar storage design page or book a demo and bring your own load profile.
