Solar Single Line Diagram: SLD Symbols and AHJ Rules

Read and draw a solar single line diagram: standard symbols, NEC, IEC and AS/NZS conventions, an 8 kW worked example and AHJ review tips.

Rainer Neumann

Written by

Rainer Neumann

Editorial contributor · SurgePV

Keyur Rakholiya

Edited by

Keyur Rakholiya

CEO & Co-Founder · SurgePV

Published ·Updated

Answer

A solar single-line diagram (SLD) is a simplified drawing of a solar PV (photovoltaic) system. One line stands for all the wires between two points. Each part gets a standard symbol and its ratings. The parts include modules, inverter, disconnects, protection, meter and grid connection. Permit reviewers and utilities ask for one, and they set the exact content.

Last updated: November 2026

SurgePV publishes this post and sells solar design software.

The solar single-line diagram is the first thing a plan checker opens and the last drawing an installer wants to redraw. Plenty of SLDs are still drawn in generic CAD (computer drawing) tools. They have copied symbols, mismatched labels, and no link to the live design data.

This guide covers the symbols that show your intent. It covers the standards that keep drawings consistent across markets. It also covers the habits that keep an SLD accurate from design through commissioning, the final checks before a system goes live. Maybe you already know what an SLD is. If you want your drawings to pass AHJ review with fewer corrections, this guide is for you. The AHJ is the authority having jurisdiction, the office that enforces the code and approves your permit.

In this guide:

  • What a solar single-line diagram is and what it is not
  • The standard symbols for modules, inverters, protection, and grounding
  • How to read an SLD from array to grid
  • A worked example with the arithmetic shown
  • Code-library differences across NEC, IEC, and AS/NZS markets
  • Drawing best practices that reduce plan-check comments
  • The most common SLD mistakes and how to fix them
  • What to look for in SLD software

Draw the SLD from your design data

SurgePV supports electrical workflow alongside layout, shading, yield and bill-of-materials output, so the drawing and the design start from the same numbers.

Book a Demo

Checking cost first? See the SurgePV pricing page.


What Is a Solar Single-Line Diagram?

A solar single-line diagram is a simplified electrical drawing of a PV system. It uses single-line notation, so one line stands for all conductors between two points. A three-phase AC cable, a DC positive/negative pair, and a grounding conductor each appear as a separate single line.

The purpose is clarity at a glance. A reviewer should be able to trace power from the PV array to the utility point of interconnection, where the system joins the grid. The reviewer should also be able to check that every part is sized, protected, and labeled. The SLD does not show physical wire routing, conduit bends, or terminal numbers. Those live in the wiring diagram and site layout.

GreenLancer’s solar one-line diagram guide says the drawing shows the major PV equipment and the electrical path between parts. These are typically modules, strings, inverters, conductors, overcurrent protection, disconnects, service equipment, and the point of interconnection. The drawing also carries the ratings and calculations a reviewer needs. The reviewer uses them to check the design against the National Electrical Code (NEC) and local rules. GreenLancer sells permit design services. So read its guide as one practitioner’s checklist, not as the code.

For a deeper definition, see the electrical SLD glossary.


SLD vs. Wiring Diagram vs. Layout Drawing

These three documents are often confused. They work together. You cannot swap one for another.

Document What it shows Typical use
Single-line diagram (SLD) Electrical relationships, component ratings, protection Permit review, AHJ approval, utility interconnection
Wiring diagram / three-line diagram Individual conductors, terminals, and connection points Installation, commissioning, troubleshooting
Layout drawing / site plan Physical location of panels, inverters, conduit routes Construction, inspection, fire department review

GreenLancer notes that most residential PV permit packages use one-line diagrams. Three-line diagrams are more common on complex commercial, three-phase, or engineered projects. It also notes that the format you need depends on the AHJ, utility and project scope. The three-line diagram, explained in our electrical three-line diagram glossary, is the next step up in detail.

The SLD is the map. The wiring diagram is the turn-by-turn directions. The layout drawing is the satellite view. Each answers a different question. A reviewer who cannot find an answer on one will look on another, usually with a correction note attached.


Standard Symbols Every Solar SLD Uses

Symbols are the vocabulary of an SLD. Non-standard symbols force the reviewer to guess your intent. Most solar drawings follow one of two standards. They are IEEE 315 (graphic symbols for electrical and electronics diagrams) and IEC 60617. The symbols differ between the two. So draw from the one your reviewer expects. The APEC training material on common electrical drawing symbols compares IEC and NEMA (IEEE/ANSI) symbols side by side and advises using locally accepted symbols.

Core Solar SLD Components and What to Label

Component What to label
PV module / string Pmax (Wp), Voc, Isc, quantity per string
Inverter Manufacturer and model, kW AC, DC voltage range, AC output voltage
Disconnect switch Voltage rating, current rating, enclosure type
Fuse Current (A), voltage (V), type
Circuit breaker Trip rating (A), poles
Surge protective device (SPD) Voltage rating and type
Busbar Ampacity, material, number of poles
Ground / earth Conductor size, grounding electrode type
Meter Bidirectional or import-only, CT ratio where used
Transformer kVA, primary and secondary voltage

The PV module symbol is often a rectangle with diagonal lines for the cells. The inverter is often a larger rectangle with a DC input side and an AC output side. The exact look varies by drafting tool, but you should be able to recognize each part at once.

Symbol Style Choices That Matter

Line weight carries meaning. Main power conductors should be heavier than monitoring or communication lines. Show ground connections differently from current-carrying conductors. Then a reviewer cannot confuse an equipment ground with a grounded DC conductor.

Text placement matters too. Labels should sit next to the component without crossing lines. Horizontal text is easier to read than vertical text. Give every symbol a unique reference label such as “INV-1,” “F1,” or “SPD-1.” The reviewer can then cross-check it against the BOM (bill of materials, the parts list) and the equipment schedule. Add a legend to the drawing even when your symbols are standard.


How to Read a Solar SLD from Array to Grid

You read an SLD left to right or top to bottom, following the current. Start at the PV source and stop at the point of interconnection.

DC Side: Array to Inverter

  1. PV modules grouped into strings. Each string is a series chain of modules. The label shows the number of modules per string and the number of strings. It also shows the module ratings at standard test conditions (the lab conditions used to rate modules).
  2. Combiner equipment (if used). Where strings join before the inverter, the combiner box holds the string overcurrent protection that the design needs. This means fuses or breakers that stop too much current.
  3. DC surge protective device (SPD). It limits voltage spikes from lightning or switching.
  4. DC disconnect / isolator. A hand-operated switch that lets service staff cut the array off from the inverter. Show its voltage rating, current rating and location (see NEC 690.13 and your AHJ).
  5. Inverter DC input. Shows the MPPT (maximum power point tracking) channel assignments, meaning which strings feed which input. It also confirms that string voltage stays inside the inverter’s MPPT window at the site’s hottest and coldest temperatures.

AC Side: Inverter to Grid

  1. Inverter AC output. Shows rated AC power, voltage, and frequency.
  2. AC disconnect. Isolates the inverter from the building wiring. For sizing guidance, see our post on AC disconnect sizing.
  3. Overcurrent protection. The breaker or fuse protecting the inverter output circuit.
  4. Residual current device (RCD). It cuts power fast if current leaks to earth. Some markets require one. Show its sensitivity and type where the local rules ask for it.
  5. kWh meter. Bidirectional, so it counts power in both directions, for net metering or feed-in tariff arrangements. Learn more in the net metering glossary.
  6. Point of interconnection. The main service panel, supply-side tap, or distribution board where the PV system connects to the utility.

A well-drawn SLD makes this path impossible to misread. A poorly drawn one forces the reviewer to backtrack, which is when correction notes appear.


Worked Example: 8 kW Residential String-Inverter SLD

This is what the labels look like for a typical U.S. home system, with the maths shown. The module and inverter values are examples only. Replace them with your datasheet values. Size conductors and overcurrent devices with the NEC edition your AHJ has adopted.

System: 8 kW DC, 20 modules at 400 W each, two strings of 10 modules, one 7.6 kW string inverter, 240 V split-phase service, 200 A busbar with a 200 A main breaker. The busbar is the metal bar in the main panel that feeds the breakers.

DC Side Labels

Element Label on SLD
PV modules 20 x 400 Wp = 8,000 Wp, Voc 41.1 V, Isc 10.2 A, 2 strings of 10
Circuit current per string 10.2 A x 1.25 = 12.75 A
Two strings in parallel 2 x 10.2 A x 1.25 = 25.5 A
Max system voltage at -10°C 10 x 41.1 V x (1 + 0.0027 x 35) = 449.8 V
DC conductors Size and wiring method from your ampacity calculation (NEC 690.8)

The voltage line assumes a Voc temperature coefficient of -0.27 %/°C. This is an example value, so use your module datasheet. Voc is the open-circuit voltage, the highest voltage a module gives with no load. Each degree below 25°C raises Voc by 0.27%. The design low of -10°C is 35 degrees below the 25°C test condition. So the correction factor is 1 + 0.0027 x 35 = 1.0945.

AC Side Labels

Element Label on SLD
Inverter AC output 7.6 kW at 240 V: 7,600 / 240 = 31.7 A
Overcurrent device 31.7 A x 1.25 = 39.6 A, so a 40 A, 2-pole breaker
Busbar check (120% method) 200 A busbar x 1.2 = 240 A. 240 A - 200 A main = 40 A maximum backfeed. The 40 A breaker fits.
AC conductors Size and wiring method from your ampacity calculation
Production meter Bidirectional revenue meter at the utility service point
8 kW example: the currents an SLD has to show (amps)
  • One string (Isc x 1.25)12.75 A
  • Two strings in parallel25.5 A
  • Inverter AC output31.7 A
  • Overcurrent device minimum39.6 A
  • Maximum backfeed (120% rule)40 A

Source: the worked example above (illustrative module and inverter values, not a product datasheet), checked November 2026.

Key Takeaway

In this example the 39.6 A minimum rounds up to a 40 A breaker, which exactly matches the 40 A backfeed the 120% method allows. A 50 A breaker would fail the busbar check, and the reviewer will look for that line.

This is why labels cannot be generic. “10 modules per string” is not enough. The reviewer needs Voc, Isc (short-circuit current), and the corrected maximum voltage to check NEC 690.7 and 690.8. The 120% busbar method is one of the NEC 705.12 options for a load-side connection (see GreenLancer’s note on it). Confirm which method your AHJ accepts.


Code Libraries: NEC, IEC, and AS/NZS Conventions

The symbol library you use must match the code the reviewer enforces. Mixing libraries is a common error on multinational projects.

NEC / IEEE 315 (United States)

  • Symbols follow IEEE 315 graphical conventions.
  • Labels use AWG (American Wire Gauge) for wire size and inch-based sizes for conduit.
  • Show maximum voltage, circuit current and overcurrent devices against NEC 690.7, 690.8 and 690.9.
  • Rapid shutdown is a system that quickly lowers the voltage on wiring near the array. Show the rapid shutdown initiator (the device that starts it) and the system configuration where NEC 690.12 applies.
  • Grounding follows NEC Article 250 and 690.45 to 690.47.
  • Name the NEC edition in the notes. It should be the edition the AHJ enforces.

IEC 60617 (Europe and much of Asia)

  • Symbols follow IEC 60617.
  • Labels use mm² for conductor cross-section and metric conduit sizes.
  • Residual current devices are specified by sensitivity in mA.
  • Earthing is the usual term here, not grounding.

India

  • DISCOM (distribution company, the local power utility) and state rules differ. Before you draw, ask the DISCOM for its SLD format and symbol rules. Follow its checklist, including any separate earthing drawing it asks for.

AS/NZS 3000 (Australia and New Zealand)

  • Where the network operator asks for it, symbols should preferably follow AS/NZS 3000 Appendix J Figure J1.
  • Jemena is an electricity network operator in Victoria, Australia. Its requirements for residential solar and battery applications (Jemena SLD requirements PDF) also ask for three things. The first is a title block (drawing name, unique drawing number, version, designer and authoriser, date, NMI address). The second is padlockable and labelled main solar and battery switches. The third is details that match the online application.

Jemena’s requirements list three things as not accepted: hand-drawn sketches, SLDs with incorrect information, and SLDs that do not match the online application. They ask for an electronic format and name AutoCAD and Microsoft Visio as common software. Other network operators set their own rules. Check the one that serves your site.


Best Practices for Drawing a Solar SLD

Drawing a correct SLD is only half the job. Keeping it correct through design changes, swapped equipment, and resubmissions is the other half.

1. Start with the Code Library, Not the Canvas

Set the standard before you place the first symbol. The library drives every label, every overcurrent value, and every conductor table. Switching from IEC to NEC halfway through a project is a sure way to create contradictions.

2. Use Standard Symbols and a Legend

Add a legend to the drawing even when your symbols are standard. Reviewers in smaller areas may not see solar SLDs every day. A legend clears up doubt and cuts questions.

3. Label Every Cable Segment

Every line on the drawing needs a label. Give the conductor size, insulation type, conduit type and size, and number of conductors. GreenLancer’s list of common plan-check corrections includes two items. One is a conductor type or wiring method that does not match the installation. The other is conductor calculations that leave out temperature correction or ampacity adjustment factors. Ampacity is how much current a wire can safely carry.

4. Size Overcurrent Devices Against the Full Derating Chain

Start with module Isc and apply the 125% factor. Then apply the ampacity checks in NEC 690.8(B). These are temperature correction and adjustment factors for the number of current-carrying conductors. Showing only the 125% step is not enough. See the string sizing and Voc correction guide for the voltage side.

5. Show the Voltage with Temperature Correction

Maximum system voltage is Voc corrected for the site’s lowest expected temperature. It is not the module nameplate value. Take the example -0.27 %/°C coefficient. A 15-module string of 40.5 V modules has 607.5 V of nameplate Voc. At a -10°C design low, it is 607.5 x 1.0945 = 664.9 V. GreenLancer cites a 600 V limit for PV DC circuits on or in one- and two-family dwellings. So the uncorrected figure would hide a problem. The SLD must show the corrected value.

Pro Tip

Before you export the drawing, search it for every model number and compare each one with the BOM and the cut sheets. This catches the most common plan-check correction in about five minutes.

6. Document Rapid Shutdown Clearly

Show the initiator and the equipment that provides rapid shutdown. Add enough detail to show how the system meets the controlled-conductor and voltage-limit requirements. Make the markings match the NEC edition the AHJ has adopted.

7. Match the SLD to the Bill of Materials

Every model number on the SLD must match the cut sheets (the makers’ data sheets) and the BOM. A 10 kW inverter on the drawing but an 8 kW inverter in the BOM is a common plan-check correction. Our related post on single-line diagrams for solar PV permits covers permit-specific requirements in more detail.

8. Include a Title Block and Revision History

The title block needs the project address, drawing number, revision, date, and designer. Jemena’s list is a useful minimum. It has the drawing name, unique drawing number, version number, designer and authoriser, date, and site address. Add the code edition. Each revision needs a change description and initials. This is how you prove which version the AHJ approved.

9. Check Whether a Separate Earthing Drawing Is Required

Some authorities ask for the earthing layout as a separate drawing. Treat it as required when the checklist lists it. Include the electrode type, resistance value, and bonding details it asks for.

10. Generate from Design Data When Possible

Hand drafting cuts the link between the drawing and the design. A change to string count, inverter size, or module model does not update a CAD file by itself. Software that makes the SLD from the same data as the layout and BOM removes that kind of error. For the design steps that come before the SLD, see the residential solar design workflow.


Common SLD Mistakes That Delay Permits

Most SLD corrections fall into a few groups. GreenLancer sorts them into DC-side, AC-side, rapid shutdown, grounding, and general documentation problems. Fixing them before you submit saves a resubmittal.

Mistake 1: Missing Conductor Sizes

An SLD without conductor ampacity on every segment cannot be checked against NEC 690.8. The reviewer has to ask for the calculation. That triggers a resubmit.

Mistake 2: Overcurrent Device Sized Only at 125%

The 1.25 multiplier is the starting point, not the finish. Heat and crowded conduit cut the current a wire can carry, which is called derating. This can push the required conductor size up. Show the full chain.

Mistake 3: Uncorrected DC Voltage

Listing module Voc without the temperature correction is wrong for cold sites. Calculate the maximum system voltage at the lowest expected ambient (air) temperature.

Mistake 4: Rapid Shutdown Gaps

Four gaps are common. The initiator is missing. The system configuration does not show compliance. The equipment does not match the listed rapid shutdown solution. Or the markings do not match the adopted NEC edition.

Mistake 5: Inconsistent Equipment Labels

Model numbers, ratings, and quantities on the SLD must match the BOM and cut sheets exactly. A mismatch between drawing and schedule makes the reviewer doubt the rest of the package.

Mistake 6: Hand-Drawn or Illegible Diagrams

Some network operators do not accept hand sketches. Jemena’s requirements are one example. Use CAD or software-made output. Keep line weights and text sizes easy to read when printed at half scale.

Mistake 7: Wrong Code Library

Send an NEC-labeled SLD to an IEC market, or an IEC-labeled SLD to a U.S. AHJ, and the reviewer sees you did not read the local rules. Confirm the adopted code and symbol standard before you draw.


Tradeoff: Hand Drafting vs. Auto-Generated SLDs

Some engineers prefer hand drafting in CAD because it gives full control over every line and note. That control is real. But every design change becomes a manual update. Swap the inverter, add two modules to a string, or change the conductor size, and the SLD, string list, and BOM can fall out of sync.

Software that makes the SLD from the design data removes that drift. A change in one place updates the drawing. The tradeoff is less control over how the drawing looks. That matters on complex commercial projects that need an engineer-sealed three-line diagram. A practical split is to make the first draft from design data. Then have the responsible engineer review and refine it where the project or the authority requires.


What to Look for in SLD Software

Software that makes SLDs from the electrical design can keep the SLD, string list, BOM, and proposal in step when the module count changes. When you compare tools, check these points on a project you know well:

  • Single source of data. Does the SLD read from the same data as the layout, string design, and BOM?
  • Symbol library. Can you choose the library your reviewer expects (IEC 60617, IEEE 315, AS/NZS 3000 Appendix J)?
  • Visible calculations. Are voltage correction, circuit current, overcurrent device and conductor ampacity shown, with the code edition they use?
  • Editable output. Can you override labels, reposition nodes and add notes without breaking the link to the design?
  • Export formats. Does it produce the formats your reviewer and utility accept (PDF, CAD)?
  • Revision control. Does it carry a title block, version and change history?
  • Engineer review path. Is it clear who checks and signs the output where the project needs an engineer?

SurgePV covers roof modeling, array layout, shading analysis, energy-yield modeling, electrical workflow support, bill-of-materials output and proposals. Ask in a guided demo which SLD outputs, symbol libraries and export formats are available for your market. Test them on your own project, and judge SurgePV by the same points as any other tool. The electrical design and SLD hub covers string sizing, protection devices and SLD basics in more depth.

Does your SLD tool pass these seven checks?

Bring a live project and run the checklist above. The demo shows how SurgePV supports electrical design alongside layout, shading, yield and the BOM.

See a Live Walkthrough

Checking cost first? See the SurgePV pricing page.


Conclusion: Three Actions for Cleaner SLDs

  1. Pick the code library first. Match symbols and labels to the jurisdiction before placing the first component.
  2. Label every segment completely. Conductor size, insulation, conduit, overcurrent rating, and equipment model numbers should leave no question for the reviewer.
  3. Generate from design data. Link the SLD to the same data as the layout and BOM so changes carry through.

Related reading: single-line diagrams for solar PV permits covers the permit side, and solar design software shows how the drawing links to the design. To see it on your own project, book a demo.

Further Reading

For the next level of detail after the SLD, see the electrical three-line diagram glossary entry and the string sizing and Voc correction guide.

A clean SLD does more than pass plan check. It becomes the reference that installers, commissioning engineers, and maintenance technicians use for the life of the system.


Frequently Asked Questions

What is a solar single-line diagram?

A solar single-line diagram (SLD) is a simplified electrical drawing of a PV system’s major parts and connections, in single-line notation. It shows the path from PV modules through the inverter to the grid. It also shows disconnects, overcurrent protection, and grounding. Permit reviewers and utilities commonly ask for one. Each sets its own content and format rules.

What symbols are used in a solar SLD?

Solar SLDs use standard symbols for PV modules, inverters, disconnect switches, fuses, circuit breakers, surge protective devices, busbars, transformers, meters, and ground connections. Most drawings follow one of two symbol standards, IEC 60617 or IEEE 315. Use the one your reviewer expects. In Victoria, Australia, for example, Jemena prefers symbols from AS/NZS 3000 Appendix J.

What is the difference between a single-line diagram and a wiring diagram?

A single-line diagram shows how components relate electrically, using one line for all conductors. A wiring diagram shows individual conductors, terminals and connection points. A layout drawing shows where equipment sits on the site or roof. The three serve different purposes, and you may need all of them together.

Which NEC article governs solar SLDs?

NEC Article 690 covers PV systems. Article 705 covers interconnected power sources. GreenLancer’s SLD guide ties diagram callouts to these sections. 690.7 covers maximum DC voltage. 690.8 covers circuit current and conductor ampacity. 690.9 covers overcurrent protection. 690.12 covers rapid shutdown. 690.13 covers disconnecting means. 690.45 and 690.47 cover grounding. 705.11 and 705.12 cover utility interconnection. Confirm the NEC edition and local amendments your AHJ has adopted.

What information must be labeled on a solar SLD?

Typical checks include module and inverter maker and model, string configuration, and maximum DC voltage with temperature correction. They also include circuit currents, conductor size and type, overcurrent device and disconnect ratings, the interconnection method, and the NEC edition. The reviewer’s checklist decides the final list.

What are the most common SLD mistakes?

Common corrections include the following. Maximum system voltage is shown as nameplate Voc without temperature correction. Conductor calculations are missing ampacity adjustment factors. Equipment model numbers do not match the cut sheets. A backfed breaker conflicts with the busbar rating. A rapid shutdown initiator is not identified. The NEC edition in the notes is not the one the AHJ enforces.

Should a solar SLD be drawn by hand or generated by software?

Generating the SLD from the same design data as the layout and bill of materials keeps the three in step when a module count or inverter changes. Some utilities do not accept hand sketches. Jemena’s SLD requirements for residential solar and battery applications in Victoria, Australia list hand-drawn sketches as not accepted. They ask for an electronic format such as AutoCAD or Visio.


Sources

NEC section numbers are given as GreenLancer cites them and have not been checked against the NFPA 70 text.

Where this fits

This article is part of SurgePV's Solar Design hub, which works through the topic from first principles to the decisions a project team actually has to make.

About the Contributors

Author
Rainer Neumann
Rainer Neumann

Editorial contributor · SurgePV

Rainer Neumann is credited as an editorial contributor on SurgePV content. This profile does not assert engineering credentials, project totals, software-testing experience, education, speaking engagements, or media citations because independent verification evidence is not retained in the publication record.

Editor
Keyur Rakholiya
Keyur Rakholiya

CEO & Co-Founder · SurgePV

Keyur Rakholiya is identified by SurgePV as its CEO and a company co-founder. His SurgePV author page lists only role information that can be tied to the public profile below; credentials, project totals, testing claims, media appearances, and speaking engagements are not asserted without retained evidence.

Get Solar Design Tips in Your Inbox

Join 2,000+ solar professionals. One email per week - no spam.

No spam · Unsubscribe anytime

Book Free Demo

Choose which optional technologies SurgePV may use. Essential storage remains active for security and requested features.
