Off-Grid Solar System Calculator: Formulas and Examples

Size an off-grid solar system with four formulas, a winter sun-hours table for ten cities, and three worked examples you can check line by line.

Rainer Neumann

Written by

Rainer Neumann

Editorial contributor · SurgePV

Rainer Neumann

Edited by

Rainer Neumann

Editorial contributor · SurgePV

Published ·Updated

Answer

To size an off-grid solar system, add up your daily watt-hours. Divide by system efficiency and by the sun hours in your darkest month to get array watts. Multiply daily watt-hours by days without sun, then divide by usable battery depth for battery size. Pick an inverter that covers your peak load and motor surge.

An off-grid system has no grid to fall back on, so the design has to hold up in the weakest month of the year. A common mistake is to size the array for summer sun when winter sun is much weaker. Use the darkest month, not the yearly average.

This guide gives four formulas you can run by hand or in a spreadsheet, a winter sun-hours table for ten cities, and three worked examples. Each example shows its arithmetic, so you can check it.

Last updated: November 2026

The four formulas

1. Daily load (Wh/day) = sum of (appliance watts x hours per day)
2. Array (W) = daily load / system efficiency / design-month sun hours x oversize factor
3. Battery (Wh) = daily load x days of autonomy / depth of discharge
4. Inverter (W) = at least your peak load, with enough surge for motors

The examples use the sizing method in the VeraSol System Design Guidelines for Component-based Off-grid Solar Energy Systems (October 2024). VeraSol is a quality assurance program for off-grid solar, managed by CLASP with the Schatz Energy Research Center. It grew out of the World Bank Group’s Lighting Global program.

In this guide:

  • How to list your daily load
  • How to find the sun hours in your darkest month
  • How to size the array, battery, inverter and charge controller
  • Three worked examples, from a cabin to a family home
  • Mistakes that cause winter failures

Already Sized It? Turn the Numbers Into a Layout

Bring your load list to a guided demo and see array layout and shading checks on a live project.

Book a Demo

Checking cost first? See the SurgePV pricing page · 20 minutes · No credit card required

Step 1: List Your Daily Load

Your daily load is the energy your appliances use in one day. For each appliance, multiply its watts by the hours it runs. VeraSol says to use the typical daily usage for this step.

Use real running watts, not the label rating. A fridge may be rated higher than its average draw because the compressor cycles on and off. A plug-in energy meter shows the true figure.

Here is an example list. The wattages are example values, not data for any product.

Appliance Quantity Watts (each) Hours per day Wh per day
LED lights 10 8 5 400
Refrigerator (average draw) 1 120 8 960
Well pump 1 2,000 0.5 1,000
Microwave 1 1,200 0.25 300
Laptop 2 60 4 480
Wi-Fi router 1 15 24 360
Phone chargers 4 10 2 80
Total 3,580

Check: 400 + 960 + 1,000 + 300 + 480 + 360 + 80 = 3,580 Wh per day.

If your list is a guess, add a margin for loads you forgot. People forget the pump, the router and standby loads.

Step 2: Find the Sun Hours in Your Darkest Month

Peak sun hours (PSH) measure how much sun reaches the panel. One peak sun hour equals 1 kWh of sunlight per square metre. So 4.5 kWh/m2 in a day is 4.5 PSH (VeraSol, section 12). PSH is not the number of daylight hours.

VeraSol picks a design month. It is the month where the sun is weakest compared with your load. If your load is the same all year, that is the month with the lowest PSH.

The table shows the darkest month for ten cities. The values come from the European Commission’s PVGIS tool (version 5.3). They are for a fixed array facing the equator, with the tilt set to the latitude, rounded to a whole degree. They are averages, so a cloudy winter can be lower. Exact values also change with the map point and the years used, so run PVGIS for your own site.

City Tilt used Darkest month PSH in that month Yearly average PSH
Berlin, Germany 53 degrees December 1.23 3.55
London, UK 52 degrees December 1.58 3.40
Seattle, WA 48 degrees December 1.78 4.02
Portland, OR 46 degrees December 1.97 4.37
Minneapolis, MN 45 degrees December 2.92 4.85
Madrid, Spain 40 degrees December 4.12 5.73
Denver, CO 40 degrees December 5.06 6.33
Phoenix, AZ 33 degrees December 5.26 6.75
Delhi, India 29 degrees July 4.40 5.92
Sydney, Australia 34 degrees June 3.99 5.41

PVGIS radiation databases: SARAH3 for London, Berlin and Madrid; ERA5 for the other cities. Sydney faces north, because it is in the southern hemisphere. Delhi’s darkest month is July because of the monsoon, not winter.

Look at the gap between the two columns. Berlin gets 3.55 PSH in an average day, but only 1.23 in December. An array sized on the yearly average would be close to three times too small for December.

Darkest-month sun hours vs yearly average, selected cities (peak sun hours per day, fixed tilt at latitude)
  • Berlin, darkest month1.23
  • Berlin, yearly average3.55
  • Portland, darkest month1.97
  • Portland, yearly average4.37
  • Minneapolis, darkest month2.92
  • Minneapolis, yearly average4.85
  • Denver, darkest month5.06
  • Denver, yearly average6.33

Source: European Commission PVGIS 5.3 runs described in the table above, checked October 2026.

Key Takeaway

The darkest month, not the yearly average, sets the array size. At the PVGIS values above, Berlin’s December gets about 35% of its yearly average sun hours (1.23 of 3.55). Denver’s December still gets about 80% (5.06 of 6.33).

A steeper tilt helps the darkest month in nine of these ten cities. In the same PVGIS runs, adding 15 degrees to the tilt raised December sun hours by about 5% in Berlin and about 10% in Phoenix. In Delhi it lowered the July figure, because the sun is high in July.

Use PVGIS or the NLR PVWatts tool to find numbers for your own site. NLR is the new name of the NREL laboratory.

Step 3: Size the Solar Array

The array has to make up for losses between the panels and your appliances. VeraSol’s worked example for a system with an MPPT controller multiplies these efficiencies: cable 0.97, MPPT controller 0.95 and battery 0.80. That gives 0.97 x 0.95 x 0.80 = 0.737.

The examples in this guide also include an assumed 0.95 inverter efficiency, which is not from VeraSol. That makes 0.737 x 0.95 = 0.70. Use the real figures from your equipment datasheets when you have them.

Array watts = daily load (Wh) / 0.70 / design-month PSH x oversize factor

The oversize factor makes the array larger than the minimum. VeraSol recommends at least 30% extra with lead-acid batteries, so they charge fully and get regular equalizing charges. It recommends 10% extra with lithium batteries, to cover module ageing. The examples below use lithium, so they use 1.1.

Then divide the result by the watts of one panel and round up.

Step 4: Size the Battery Bank

Battery (Wh) = daily load (Wh) x days of autonomy / depth of discharge

Days of autonomy are the days the battery must run your load with no sun. VeraSol says 2 to 5 days is common. It sets 1.5 days as the minimum for small home systems where price matters. For larger and remote systems it prefers 3 to 5 days.

Depth of discharge (DoD) is how much of the battery you use. Check your battery’s datasheet. VeraSol says some residential lead-acid batteries stop at 50% DoD, while some large industrial ones allow 80%. For lithium, usable energy can be anywhere from 60% to 100% of rated capacity. It also gives an example where a lithium battery lists 80% usable, and the design uses 70%. This is because some lithium batteries lock up at low charge. The examples below use 70%.

Cold weather also matters. VeraSol notes that lead-acid capacity falls as the temperature drops. If your battery sits in the cold, ask the maker for a capacity-versus-temperature chart.

Read more about round-trip efficiency and the battery size calculator. The battery sizing hub covers home batteries in more detail.

Pro Tip

Write down the battery’s usable capacity from its datasheet before you apply a depth of discharge. If the maker already lists usable energy, using a second depth-of-discharge factor on top of it double-counts the margin.

Step 5: Size the Inverter

An inverter must supply your peak load, which is the most appliances running at one time. It does not need to cover every appliance at once. VeraSol says to pick the loads that normally run together.

Motors need extra power for a moment when they start. This is the surge. VeraSol says the inverter must supply surge power, typically for 1 to 3 seconds, to start motors. Look up the surge rating of each motor in its manual or on its label.

VeraSol also gives a rule of thumb. Keep the maximum continuous battery current below 150 A, to limit cable size and voltage drop. Current is power divided by voltage. At 48 V, 5,000 W is 104 A. At 48 V, 8,000 W is 167 A, which is over the limit, so a higher battery voltage is better there.

For more on inverters, read the inverter sizing guide.

Step 6: Check the Charge Controller

A charge controller sits between the array and the battery. It manages the charge. Check two limits against your array:

  • Current. VeraSol says that unless the controller limits its own current, it should carry at least 125% of the array’s short-circuit current.
  • Voltage. The controller must withstand the array’s open-circuit voltage.

You can also estimate the charging current. Divide the array watts by the battery voltage. For a 1,200 W array on a 48 V battery, that is 1,200 / 48 = 25 A. Add a margin if you may add panels later. VeraSol advises sizing the controller larger in that case.

Worked Example 1: Small Cabin

These are example inputs, not a design. Check your own loads and equipment.

  • Location: Denver, CO. Darkest month is December, at 5.06 PSH.
  • Daily load: 3,500 Wh
  • Battery: lithium, 2 days of autonomy, 70% DoD
  • Panels: 400 W each (example)

Array. 3,500 / 0.70 = 5,000 Wh. Then 5,000 / 5.06 = 988 W. With the 1.1 oversize factor, 988 x 1.1 = 1,087 W. That is 1,087 / 400 = 2.72, so 3 panels, or 1,200 W.

Battery. 3,500 x 2 / 0.7 = 10,000 Wh, or 10 kWh.

Charging current. 1,200 W / 48 V = 25 A.

Worked Example 2: Mid-Size Home

  • Location: Portland, OR. Darkest month is December, at 1.97 PSH.
  • Daily load: 12,000 Wh
  • Battery: lithium, 3 days of autonomy, 70% DoD
  • Panels: 415 W each (example)

Array. 12,000 / 0.70 = 17,143 Wh. Then 17,143 / 1.97 = 8,702 W. With the 1.1 factor, 8,702 x 1.1 = 9,572 W. That is 9,572 / 415 = 23.07, so 24 panels, or 9,960 W.

Battery. 12,000 x 3 / 0.7 = 51,429 Wh, or about 51.4 kWh.

Charging current. 9,960 W / 48 V = 207.5 A. That is more than one controller can carry, so you would use several.

Peak current. If the peak load is 5,000 W, then 5,000 / 48 = 104 A. This is under 150 A.

Worked Example 3: Large Family Home

  • Location: Minneapolis, MN. Darkest month is December, at 2.92 PSH.
  • Daily load: 25,000 Wh
  • Battery: lithium, 3 days of autonomy, 70% DoD
  • Panels: 415 W each (example)

Array. 25,000 / 0.70 = 35,714 Wh. Then 35,714 / 2.92 = 12,231 W. With the 1.1 factor, 12,231 x 1.1 = 13,454 W. That is 13,454 / 415 = 32.4, so 33 panels, or 13,695 W. At this size you may need a ground mount.

Battery. 25,000 x 3 / 0.7 = 107,143 Wh, or about 107.1 kWh.

Peak current. If the peak load is 8,000 W, then 8,000 / 48 = 167 A. This is over VeraSol’s 150 A rule of thumb, so choose a higher battery voltage.

Results at a Glance

Case Daily load Darkest-month PSH Array Battery Charging current at 48 V
Cabin (Denver) 3.5 kWh 5.06 1,200 W (3 panels) 10 kWh 25 A
Home (Portland) 12 kWh 1.97 9,960 W (24 panels) 51.4 kWh 207.5 A
Family home (Minneapolis) 25 kWh 2.92 13,695 W (33 panels) 107.1 kWh 285 A

Compare the arrays per kWh of daily load. Portland needs about 830 W for each kWh (9,960 / 12). Minneapolis needs about 550 W (13,695 / 25). Portland’s December sun is weaker: 1.97 PSH against 2.92.

Turn Your Sizing Into a Design

Use these results as starting inputs. We will show how SurgePV handles layout, shading, financial modeling and proposals on a live project.

See a Live Walkthrough

Want the price? Read the SurgePV pricing page · Guided demo · No credit card required

What Do Batteries Cost?

Battery pack prices fell in 2025. BloombergNEF’s 2025 Lithium-Ion Battery Price Survey (press release dated 9 December 2025) reports:

  • The average lithium-ion pack price was $108 per kWh.
  • Stationary storage packs fell to $70 per kWh, which is 45% lower than in 2024.
  • Average LFP pack prices across all segments were $81 per kWh. Nickel manganese cobalt (NMC) packs averaged $128 per kWh.

A pack price is not an installed price. The bill also includes the inverter, controller, wiring, mounting, labor and any permit. Ask installers for written quotes for your site. See the BloombergNEF press release.

Do Codes and Standards Apply?

Yes, off-grid systems still have safety rules. Ask your local permit office which electrical code it uses and whether it needs a permit and drawings. If you plan to submit a wiring drawing, read the single-line diagram guide.

You may also see IEC 62124 mentioned. It was an international standard for checking the design of stand-alone PV systems. The IEC webstore now lists it as withdrawn, with a withdrawal date of 13 July 2026 (IEC 62124:2004 page). Check with your buyer or program which standard they now use.

Keep these documents on file for every build: the load list, the sizing sheets, a wiring drawing, equipment datasheets and the test results from commissioning.

From Sizing Sheet to Design

A spreadsheet gives you the targets. The next step is to turn them into a layout, check shading and build a proposal. A winter shadow can cut the sun hours you assumed. Test it with shading analysis.

SurgePV supports roof modeling, array layout, shading analysis, energy-yield modeling, financial modeling, bill-of-materials output and proposal generation. Use your sizing results as the starting inputs, and book a demo to see it on your project. See the solar design software and solar proposals pages. For ground-mount frames, read the solar racking design guide. If you want to compare design tools for off-grid work, see Top 9 Best Off-Grid Solar Design Tools Reviewed.

For a second walk-through of the same method, see the off-grid sizing guide. For a general sizing method on grid-tied homes, see the system sizing hub.

6 Sizing Mistakes That Cause Winter Failures

1. Using the yearly average sun hours. Use the darkest month. The Berlin figures above show why.

2. Ignoring motor surge. A motor can need much more power for a moment at start-up. VeraSol says the inverter must cover the surge, typically for 1 to 3 seconds.

3. Too few days of autonomy. VeraSol prefers 3 to 5 days for larger and remote systems.

4. No room to grow. If you may add panels, VeraSol advises a larger charge controller.

5. Ignoring battery temperature. Lead-acid capacity falls in the cold. Ask for the maker’s chart.

6. Skipping the shade check. A low winter sun casts longer shadows. Check them before you finalize the array location.

Frequently Asked Questions

How do I calculate what size solar system I need?

Add up each appliance’s watts times its daily hours to get watt-hours per day. Divide by your system efficiency, then divide by the peak sun hours of your darkest month. The result is the array size in watts. Add a margin for losses over time, such as 10% for a lithium battery system, as the VeraSol guidelines suggest.

How many solar panels do I need for off-grid?

Divide the array watts by the watts of one panel, and round up. For a 5,000 W array with 425 W panels, 5,000 divided by 425 is 11.76, so you need 12 panels.

How big a battery bank do I need for 3 days of autonomy?

Multiply your daily load by 3 days, then divide by the depth of discharge you plan to use. For a 10 kWh daily load at 70% depth of discharge, 10 x 3 / 0.7 = 42.9 kWh of battery. Check the battery datasheet for its usable capacity.

Do I need a backup generator for off-grid solar?

Not always. A generator can cut the battery size you need, because it covers long cloudy spells. VeraSol’s guidelines cover hybrid systems that pair solar with a fuelled generator. Weigh the fuel and service cost against the cost of a larger battery and array.

Is lithium worth the higher cost than lead-acid?

It depends on price, life and how deep you cycle the battery. BloombergNEF reports that average lithium iron phosphate (LFP) pack prices were $81 per kWh in 2025. Pack prices are not installed prices. Compare quotes and datasheet cycle life for both types.

Can I expand my off-grid solar system later?

Yes, if you plan for it. VeraSol advises sizing the charge controller larger if you may add panels later. Leave room in the inverter, the battery rack and the wiring, and write the spare capacity in your design notes.

Final Checklist

Check Done
Load list uses real running watts ☐
Design month chosen from a sun-hours source ☐
Array sized for the darkest month ☐
Battery sized for your days of autonomy and a safe depth of discharge ☐
Inverter covers peak load and motor surge ☐
Charge controller checked for current and voltage ☐
Peak battery current checked against 150 A ☐
Shading checked for winter ☐
Local permit rules checked ☐
